Engineered for high-density modern infrastructure, this American Type 1000 kVA compact pad-mounted substation transformer delivers secure MV/HV to LV power distribution. Featuring dual 50Hz/60Hz compatibility, its rugged outdoor enclosure provides tamper-proof, weather-resistant performance without requiring protective fencing. It is the ideal plug-and-play power solution for large commercial builds, shopping centers, and mixed-use developments demanding a safe, low-profile electrical footprint.
Key Specifications
- Rated Capacity: 1000 kVA (Scalable 100-1600 kVA range)
- Voltage Class: MV/HV Primary (Typical 12.47 kV / 13.8 kV)
- Frequency: 50Hz / 60Hz Dual Compatibility
- Design Standard: American Type Pad Mount (ANSI / IEEE)
- Enclosure: Tamper-resistant Outdoor Compact Cabinet (NEMA 3R)
- Phase: Three Phase
- Cooling Method: ONAN (Oil-Immersed)
- Application Environment: Commercial Builds & Public Spaces
American Type Outdoor Compact Pad Mounted Substation Transformer 1000KW 100-1600KVA MVHV 50Hz60Hz for Commercial Build
Certified & Verified Enterprise
Ready to Upgrade Your Power Infrastructure?
Secure your energy supply with the 1000 KVA / 1250 KVA 11 KV Step Down Cast Resin Dry Type Power Transformer. Engineered with CRGO core and UL certification for maximum reliability. Get factory-direct pricing and professional engineering support today.
Technical Specifications
Comprehensive parameters for the American Type Outdoor Compact Pad Mounted Substation Transformer 1000KW 100-1600KVA MVHV 50Hz60Hz for Commercial Build
Need Complete Details?
Download our comprehensive product catalog and technical manual for full engineering data and installation guidelines.
Download PDF Manual| Parameter | Specification Details |
|---|---|
| Phase | Three Phase |
| Rated Capacity | 1000 kVA (Available range: 100 kVA - 1600 kVA) |
| Primary Voltage | MV/HV (Customizable up to 34.5 kV) |
| Secondary Voltage | 480Y/277 V or 400Y/230 V |
| Frequency | 50Hz / 60Hz |
| Vector Group | Dyn11 / YNyn0 |
| Cooling Method | ONAN (Oil Natural Air Natural) |
| Insulation Class | A |
| Core Material | High-Permeability Grain-Oriented Silicon Steel |
| Enclosure Rating | NEMA 3R / IP54 Tamper-Resistant Cabinet |
| Design Standard | ANSI C57.12.34, IEEE, DOE 2016 Compliant |
| Application | Commercial Builds, Public Infrastructure, Shopping Centers |
| Certification | UL, IEEE, ISO9001 |
| Warranty | 24 Months |
Get Your Customized Power Solution
Provide your project requirements and our technical engineers will generate a detailed, competitive quotation for the 1000 KVA / 1250 KVA Cast Resin Dry Type Transformer within 12 hours.
12470V / 11KV Step Down Cast Resin Transformer
- Cooling: AN/AF
- Standard: IEC 60076/ANSI
- Vector Group: Dyn11 / Yyn0
- Voltage: 415V / 400V Output
If you have urgent technical questions or bidding deadlines, feel free to contact our senior engineering sales team directly:
Tel / WhatsApp: +8617502139434
Email: sales@millenium-electric.com
Visit Contact Page →We offer full customization for voltage ratings, winding materials (Copper/Aluminum), and enclosure dimensions to seamlessly integrate with your existing power infrastructure and comply with local grid standards.
We provide secure, sea-worthy vacuum packing to prevent humidity and corrosion during transit to any global sea port. Backed by a standard 1-Year comprehensive warranty with lifetime remote technical support.
