Designed for American distribution networks, this 3-phase padmounted compact substation transformer is engineered with selectable capacities of 630 kVA, 1250 kVA, and 1600 kVA alongside 13 kV and 30 kV primary voltage options. Housed in a completely tamper-resistant enclosure, it efficiently delivers step-down power directly to open-access shopping centers, industrial parks, and residential neighborhoods without requiring traditional fenced yards.
Key Specifications
- Transformer Type: Pad-Mounted Compact Power Substation
- Phase System: 3-Phase
- Rated Capacity: 630 kVA / 1250 kVA / 1600 kVA
- Primary Voltage: 13 kV / 30 kV
- Secondary Voltage: 480Y/277V
- Cooling Method: ONAN (Oil Natural Air Natural)
- Application Standard: American Distribution (ANSI/IEEE)
- Enclosure: NEMA 3R Tamper-Resistant
American Distribution 3 Phase Padmounted transformers Substation 1250 KVA 1600kVA 630kVA 13kV 30 KV Compact Power Transf
Certified & Verified Enterprise
Ready to Upgrade Your Power Infrastructure?
Secure your energy supply with the 1000 KVA / 1250 KVA 11 KV Step Down Cast Resin Dry Type Power Transformer. Engineered with CRGO core and UL certification for maximum reliability. Get factory-direct pricing and professional engineering support today.
Technical Specifications
Comprehensive parameters for the American Distribution 3 Phase Padmounted transformers Substation 1250 KVA 1600kVA 630kVA 13kV 30 KV Compact Power Transf
Need Complete Details?
Download our comprehensive product catalog and technical manual for full engineering data and installation guidelines.
Download PDF Manual| Parameter | Specification Details |
|---|---|
| Phase | 3-Phase |
| Rated Capacity | 630 kVA / 1250 kVA / 1600 kVA |
| Primary Voltage | 13 kV / 30 kV |
| Secondary Voltage | 480Y/277V |
| Frequency | 60 Hz |
| Vector Group | Dyn1 |
| Cooling Method | ONAN |
| Insulation Class | Class A (105°C) |
| Core Material | High-Permeability Grain-Oriented Silicon Steel |
| Design Standard | ANSI C57.12.34 / IEEE C57.12.00 |
| Application | American Utility, Industrial & Commercial Substation |
| Certification | UL / IEEE / DOE 2016 Compliant |
| Warranty | 24 Months |
Get Your Customized Power Solution
Provide your project requirements and our technical engineers will generate a detailed, competitive quotation for the 1000 KVA / 1250 KVA Cast Resin Dry Type Transformer within 12 hours.
12470V / 11KV Step Down Cast Resin Transformer
- Cooling: AN/AF
- Standard: IEC 60076/ANSI
- Vector Group: Dyn11 / Yyn0
- Voltage: 415V / 400V Output
If you have urgent technical questions or bidding deadlines, feel free to contact our senior engineering sales team directly:
Tel / WhatsApp: +8617502139434
Email: sales@millenium-electric.com
Visit Contact Page →We offer full customization for voltage ratings, winding materials (Copper/Aluminum), and enclosure dimensions to seamlessly integrate with your existing power infrastructure and comply with local grid standards.
We provide secure, sea-worthy vacuum packing to prevent humidity and corrosion during transit to any global sea port. Backed by a standard 1-Year comprehensive warranty with lifetime remote technical support.
