1000kVA 2000kVA 10kV 20kV Dry Type Resin Casting Dyn11 Transformer for Data Center 50 60Hz ANSI IEC
1000kVA 2000kVA 10kV 20kV Dry Type Resin Casting Dyn11 Transformer for Data Center 50 60Hz ANSI IEC Certified Copper Al
Engineered exclusively for mission-critical infrastructure, this 1000kVA to 2000kVA cast resin dry-type transformer safely steps down 10kV or 20kV primary grids for flawless power distribution. Featuring a highly reliable epoxy resin casting and a Dyn11 vector group, it is optimized to meet the zero-downtime demands of modern indoor data centers. ANSI and IEC certifications guarantee uncompromising safety, efficiency, and continuous 50/60Hz performance.
Key Specifications
- Rated Capacity: 1000 kVA / 2000 kVA
- Primary Voltage: 10 kV / 20 kV
- Secondary Voltage: 400 V / 415 V
- Frequency: 50 Hz / 60 Hz
- Vector Group: Dyn11
- Cooling Method: AN / AF (Air Natural / Air Forced)
- Winding Material: Copper / Aluminum
- Certification: ANSI, IEC
1000kVA 2000kVA 10kV 20kV Dry Type Resin Casting Dyn11 Transformer for Data Center 50 60Hz ANSI IEC Certified Copper Al
Certified & Verified Enterprise
Ready to Upgrade Your Power Infrastructure?
Secure your energy supply with the 1000 KVA / 1250 KVA 11 KV Step Down Cast Resin Dry Type Power Transformer. Engineered with CRGO core and UL certification for maximum reliability. Get factory-direct pricing and professional engineering support today.
Technical Specifications
Comprehensive parameters for the 1000kVA 2000kVA 10kV 20kV Dry Type Resin Casting Dyn11 Transformer for Data Center 50 60Hz ANSI IEC Certified Copper Al
Need Complete Details?
Download our comprehensive product catalog and technical manual for full engineering data and installation guidelines.
Download PDF Manual| Parameter | Specification Details |
|---|---|
| Phase | Three Phase |
| Rated Capacity | 1000 kVA / 2000 kVA |
| Primary Voltage | 10 kV / 20 kV |
| Secondary Voltage | 400 V / 415 V |
| Frequency | 50 Hz / 60 Hz |
| Vector Group | Dyn11 |
| Cooling Method | AN / AF (Air Natural / Air Forced) |
| Insulation Class | Class F or H |
| Core Material | High-permeability Grain-oriented Silicon Steel |
| Winding Material | Copper (Cu) / Aluminum (Al) |
| Design Standard | ANSI C57.12.01, IEC 60076-11 |
| Application | Data Centers, Critical Indoor Infrastructure |
| Certification | ANSI, IEC |
| Warranty | 24 Months |
Get Your Customized Power Solution
Provide your project requirements and our technical engineers will generate a detailed, competitive quotation for the 1000 KVA / 1250 KVA Cast Resin Dry Type Transformer within 12 hours.
12470V / 11KV Step Down Cast Resin Transformer
- Cooling: AN/AF
- Standard: IEC 60076/ANSI
- Vector Group: Dyn11 / Yyn0
- Voltage: 415V / 400V Output
If you have urgent technical questions or bidding deadlines, feel free to contact our senior engineering sales team directly:
Tel / WhatsApp: +8617502139434
Email: sales@millenium-electric.com
Visit Contact Page →We offer full customization for voltage ratings, winding materials (Copper/Aluminum), and enclosure dimensions to seamlessly integrate with your existing power infrastructure and comply with local grid standards.
We provide secure, sea-worthy vacuum packing to prevent humidity and corrosion during transit to any global sea port. Backed by a standard 1-Year comprehensive warranty with lifetime remote technical support.
