1000 KVA 1 MVA 33kV 22kV 11kV to 433V 400V Electrical Distribution Transformer Package Substation Pr
1000 KVA 1 MVA 33kV 22kV 11kV to 433V 400V Electrical Distribution Transformer Package Substation Price
The 1000 kVA (1 MVA) Package Compact Substation is an all-in-one electrical distribution solution designed to step down versatile high-voltage inputs ranging from 33kV, 22kV, or 11kV to standard 433V or 400V secondary outputs. Integrating a robust distribution transformer, medium-voltage switchgear, and low-voltage panels into a weather-proof enclosure, it is engineered for rapid, space-saving deployment in urban infrastructure, industrial parks, and utility grid extensions.
Key Specifications
- Rated Capacity: 1000 kVA (1 MVA)
- Primary Voltage: 33 kV / 22 kV / 11 kV
- Secondary Voltage: 433 V / 400 V
- Configuration: Package Compact Substation (MV + Transformer + LV)
- Phase: Three-Phase
- Vector Group: Dyn11
- Enclosure Protection: IP54 (Outdoor Weatherproof)
- Cooling Method: ONAN (Transformer) with Enclosure Ventilation
1000 KVA 1 MVA 33kV 22kV 11kV to 433V 400V Electrical Distribution Transformer Package Substation Price
Certified & Verified Enterprise
Ready to Upgrade Your Power Infrastructure?
Secure your energy supply with the 1000 KVA / 1250 KVA 11 KV Step Down Cast Resin Dry Type Power Transformer. Engineered with CRGO core and UL certification for maximum reliability. Get factory-direct pricing and professional engineering support today.
Technical Specifications
Comprehensive parameters for the 1000 KVA 1 MVA 33kV 22kV 11kV to 433V 400V Electrical Distribution Transformer Package Substation Price
Need Complete Details?
Download our comprehensive product catalog and technical manual for full engineering data and installation guidelines.
Download PDF Manual| Parameter | Specification Details |
|---|---|
| Phase | Three Phase |
| Rated Capacity | 1000 kVA (1 MVA) |
| Primary Voltage | 33 kV / 22 kV / 11 kV |
| Secondary Voltage | 433 V / 400 V |
| Frequency | 50 Hz / 60 Hz |
| Vector Group | Dyn11 |
| Cooling Method | ONAN (Internal Transformer) / Natural Air (Enclosure) |
| Insulation Class | Class A (Liquid-Filled Equivalent) |
| Core Material | High-Permeability Cold-Rolled Grain Oriented (CRGO) Silicon Steel |
| Equipment Layout | MV Switchgear, Distribution Transformer, LV Protection Panel |
| Design Standard | IEC 62271-202, IEC 60076 |
| Application | Urban Grid Distribution, Industrial Facilities, Wind/Solar Parks |
| Certification | IEC, CE, ISO 9001 |
| Warranty | 24 Months Standard |
Get Your Customized Power Solution
Provide your project requirements and our technical engineers will generate a detailed, competitive quotation for the 1000 KVA / 1250 KVA Cast Resin Dry Type Transformer within 12 hours.
12470V / 11KV Step Down Cast Resin Transformer
- Cooling: AN/AF
- Standard: IEC 60076/ANSI
- Vector Group: Dyn11 / Yyn0
- Voltage: 415V / 400V Output
If you have urgent technical questions or bidding deadlines, feel free to contact our senior engineering sales team directly:
Tel / WhatsApp: +8617502139434
Email: sales@millenium-electric.com
Visit Contact Page →We offer full customization for voltage ratings, winding materials (Copper/Aluminum), and enclosure dimensions to seamlessly integrate with your existing power infrastructure and comply with local grid standards.
We provide secure, sea-worthy vacuum packing to prevent humidity and corrosion during transit to any global sea port. Backed by a standard 1-Year comprehensive warranty with lifetime remote technical support.
